Specifications
| Supply voltage | 24 V AC ± 10%, 50/60 Hz |
|---|---|
| Load | Max. 6 A (speed) |
| Outputs | 2 proportional 0…10 V DC (R L > 10 kOhm) |
| Power consumption | 1 W |
| Sensor | NTC 100K |
| Ambient temperature | 0…40°C |
| Ambient humidity | 10…90 % RH (non-condensing) |
| Setpoint | 5…30°C |
| Storage temperature | -20…+70°C |
| Storage humidity | < 95% RH |
| P-band | 1…5 K |
| Neutral zone | 1…4K |
| Casing | ABS fireproof according to UL94 V-0 color (RAL 9010) |
| Weight | 0.21 |
| Dimensions | 144 x 82 x 34mm |
| Protection class | IP30 |
| Isolation class | II |
