Temperature transmitter for room mounting, 0…10 V and Modbus

The wall-mounted TTA transmitter series is designed for accurate temperature measurement in indoor environments. Available with or without display, these transmitters offer reliable performance and easy integration for building and HVAC applications.

Specifications
Software & documentation

Articles

(4 st)
  • TTA - Regin
    TTA
    Temperature transmitter
    Measuring range, temp
    0…50 °C
    Output temperature
    0-10 V
  • TTA-D - Regin
    TTA-D
    Temperature transmitter with display
    Display
    Yes
    Display type
    LCD
    Measuring range, temp
    0…50 °C
    Output temperature
    0-10 V
  • TTA-M - Regin
    TTA-M
    Temperature transmitter
    Measuring range, temp
    0…50 °C
    Output temperature
    Modbus
  • TTA-D-M - Regin
    TTA-D-M
    Temperature transmitter with display
    Display
    Yes
    Display type
    LCD
    Measuring range, temp
    0…50 °C
    Output temperature
    Modbus

Specifications

Specifications for Temperature transmitter for room mounting, 0…10 V and Modbus
Power Supply 24VAC/DC (22...26 V AC 50Hz / 15...35 V DC), VA
Appliance class Class III
Protection class IP30
Ambient humidity (non-condensing) 10…90 % RH
Ambient temperature 0…50 °C
Mounting Room, Wall
Dimensions, external (WxHxD) 100x85x30 mm
Accuracy, temperature ±0.4 K
Terminal type Screw Terminal
Terminal wire size 0.75 mm²
Power consumption < 1 W
Transformer power ≤2 VA
Power supply 24 Vac ±10% / 15...35 Vdc
