DMN24FS Damper actuators with spring return, 5 Nm
Well-suited for applications with security dampers used as antifreeze, antismoke or for sealing in the hygienic-sanitary field.
Specifications
| Supply voltage | 24 V AC/DC |
|---|---|
| Power consumption | 7 VA (5 W - Running / 2.5 W - Holding) |
| Control signal | 0...10 Vdc |
| Feedback signal | 0...10 Vdc |
| Running time, spring | 20 s |
| Switching capacity (Auxiliary) | 3 (1.5) A, 230 Vac (x2 SPDT) |
| Auxiliary switch | Yes |
| Damper shaft, min shaft length | 80 mm |
| Angle limitation | 5...85° in 5° steps |
| Running time, actuator (range) | 90...120 s |
| Appliance class | Class II |
|---|---|
| Protection class | IP54 |
| Ambient humidity (non-condensing) | 5…95 % RH |
| Ambient temperature | -30…50 °C |
| Weight, incl. packaging | 1.8 kg |
| Cable length | 1 m |
| Working angle, rotation | 90 ° |
| Damper shaft, round | 10…16 mm |
| Damper shaft, square | 7…11 mm |
| Max damper size (area) | 1 m² |
| Torque | 5 Nm |
| Frequency | 50...60 Hz |
